YE3L Series IE3 Super High Efficiency Aluminum Frame Three Phase Induction Motors

Frame sizes:63 to 160
Rated output: 0.12 to 18.5kW
Voltage: 380V
Frequency: 50Hz or 60Hz
Number of poles: 2, 4, 6, 8
Efficiency levels: IE3
Duty Cycle: S1
Enclosure: IC411 – TEFC
Insulation class: F
Degree of protection: IP55
Hotline:
+86 551 6389 0501
Fax:
+86 551 6389 0501
E-Mail:
info@wnmotor.com
Download:
YE3L Series IE3 Super High Efficiency Aluminum Frame Three Phase Induction Motors Documentation

Detail

YE3L Series Documentation

Aluminum frame
Beautiful profile
High efficiency and energy saving (IE3 of IEC60034-30 and level 2 of GB18613-2012)
Low noise
Little vibration
Reliable performance
Inverter Duty Rated: 2:1CT & 10:1VT at 380V 50 Hz
High lock rotor torque
Junction box equipped with glands
F2 mounting position, F1, F3 is available too
Bidirectional fan
Over sized ball bearings on both ends for direct coupling

General purpose including cutting machines, pumps, fans, conveyors, machines tools of farm duty and food process etc. Particularly suited to the OEM and Re-sale (Distribution) markets, this series provides an optimal balance between standard product features, reduced weight, rapid availability and competitive pricing.

Common frame size corresponding to the power:

Frame Size	63	71	80	90	100	112	132	160
Power range kW	0.12~0.25	0.18~0.55	0.18~1.1	0.37~2.2	0.75~3	1.5~4	2.2~7.5	4~18.5
Poles	2.4	2.4.6	2.4.6.8	2.4.6.8	2.4.6.8	2.4.6.8	2.4.6.8	2.4.6.8

Remark: For the other special rated powers, please contact with us.

Frame

Basic Type

Derived type

B35

V15

V36

B14

B34

V18

63~112

√

132~160

√
